DONANIM ÖZELLİKLERİ
İşlemci
Qualcomm 560MHz CPU, MIPS 74Kc
Bellek
64MB DDR2 RAM,8MB Flash
Arabirim
1 10/100Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button
Güç Kaynağı
Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) Voltage range: 16-27VDC
Boyutlar ( W X D X H )
350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.)
Anten Kazancı
23dBi
Anten Beamwidth
7°(Azimuth), 10°(Elevation)
Koruma
15KV ESD Protection 6KV Lightning Protection
Muhafaza
Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dust proof design
KABLOSUZ ÖZELLİKLERİ
Kablosuz Standartlar
IEEE 802.11a/n
Tescilli Protokol
TDMA Mode (with Pharos MAXtream enabled)
Kablosuz Hızı
Up to 150Mbps (40MHz,Dynamic) Up to 72.2Mbps (20MHz,Dynamic) Up to 36.1Mbps (10MHz,Dynamic) Up to 18.05Mbps (5MHz,Dynamic)
Frekans
5.15~5.85GHz
İletim Gücü
Max. 23dBm (Adjustable power by 1dBm)
YAZILIM ÖZELLİKLERİ
IPv6
Yes
Ağ Yapılandırma
WAN: Static/Dynamic/PPPoE/L2TP/PPTP LAN: Static/Dynamic/DHCP Forwarding: ALG/UPnP/Virtual Server/Port Trigger Security: SPI Firewall/ Ping Forbidden/DoS Protection Access Control Static Routing Bandwidth Control IP & MAC Binding
Kablosuz Konfigürasyonlar
Pharos MAXtream TDMA Technology Selectable Channel Width: 5/10/20/40MHz Auto Channel Selection Transmit Power Control Dynamic Frequency Selection(DFS) WDS Enable/Disable Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption SSID Broadcast Enable/Disable Multi-SSID with VLAN Tagging(AP Mode only) Distance/ACK Timeout Setting Wireless MAC Address Filter Wireless Advanced: Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia Long Range PtP
Yönetim
Discovery and Remote Management via Pharos Control application HTTP/HTTPS Web-based management System log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server
Sistem Araçları
Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP Spectrum Analyzer Speed Test Ping Traceroute Antenna Alignment
Sistem Düzeyindeki Optimizasyonlar
Optimized IGMP Snooping/Proxy for multicast applications
DİĞERLERİ
Sertifika
CE, FCC, RoHS, IP65
Paket İçeriği
Outdoor Wireless CPE 24V 0.25A Passive PoE Adapter Pole Mounting Kits AC Power Cord Installation Guide
Sistem Gereksinimleri
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
Ortam
Operating Temperature: -40℃~70℃ (-40℉~158℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing
3G-4G Desteği Yok Anten Dahili Ethernet Portu 1 Adet Kullanım Yeri Dış Ortam Wi-Fi Veri Transfer Hızı 150 MBPS
